TRAXXAS BIGFOOT 4WD BL-2S Monster Truck w/ 2.4Ghz Radio - 67134-4

TRAXXAS BIGFOOT 4WD BL-2S Monster Truck w/ 2.4Ghz Radio - 67134-4

Traxxas brings back the glory days of monster truck racing with the new BIGFOOT 4X4 equipped with BL-2s brushless power and Traxxas’ toughest 4X4 driveline. BIGFOOT 4X4 comes outfitted with a clipless BIGFOOT No. 8 body and factory-installed Extreme Heavy Duty components to take the most brutal punishment in stride. From the stadium to your own backyard, Traxxas delivers all-day fun and excitement with the new BIGFOOT 4X4 monster truck.

Extreme HD 4X4 Driveline

BIGFOOT 4X4 uses a shaft-driven four-wheel-drive system for extreme traction in any environment. A tough center driveshaft joins the front and rear steel-gear differentials to distribute the brushless motor’s massive torque. Huge Maxx-Duty driveshafts keep power flowing to BIGFOOT’s towering monster truck wheels with unrivaled durability. The Extreme Heavy Duty upgrade kit fortifies Bigfoot with a full complement of driveline and suspension parts designed to work in sync to make Bigfoot unstoppable.

BL-2s Brushless Power System

BIGFOOT’s waterproof BL-2s 3300kv brushless power system ramps up the fun with more torque, faster acceleration, and less maintenance than comparable brushed power systems. The BL-2s is a model of efficiency and refinement, offering more power than before with the safety and convenience that only Traxxas can deliver. BL-2S has 3 easily programmable driving modes, including training mode, Thermal Shutdown Protection and Low Voltage Detection to stop your batteries from getting too low.

Standard 2075 Steering Servo

Traxxas' long time, all purpose #2075 servo comes into use again in Bigfoot. With 9kg of torque and full waterproof sealing #2075 provides a crisp and reliable steering response.

Clipless Replica Body

BIGFOOT 4X4 comes Ready-To-Race with a beautifully detailed BIGFOOT No. 8 clipless replica body. Bright chrome bumpers stand out against the brilliant blue paint and unmistakable red and yellow stripes. BIGFOOT 4X4’s convenient hidden latching system replaces traditional body clips with clean lines and a secure hold.

New Design

Bigfoot and Stampede, two of Traxxas most iconic monster trucks, merge together to create the new design Bigfoot 4x4. Based on the newest Stampede 4x4 chassis, Bigfoot 4x4 has legendary Traxxas toughness with modular design for an unstoppable monster truck.

Monster Wheels & Tyres

Bigfoot rides high on new white monster truck wheels with replica military style axle hubs and giant Terra Groove tyres. Bigfoot has nearly 3 inches of center ground clearance to surmount any terrain obstacle and, short front and rear overhangs increase approach and departure angles to get over anything.

Waterproof Electronics

Traxxas make their cars as waterproof as possible, with full waterproof sealing on their ESCs, servos and receiver boxes. Waterproof means rain, snow and puddles are no obstacle to RC bashing fun. (Traxxas cars are NOT submersible).

Traxxas TQ Radio System

Traxxas TQ radio system has been around for a long time. It provides long range and short reaction time between radio and receiver, for a large range of Traxxas trucks. Comfortable hand-feel, glitch free performance and fast frame rate, who could ask a better radio.

Modular Design

Traxxas have perfected the art of modular, easy to dis-assemble design. Remove a few screws and Bigfoot comes apart in 3 chunks for easy cleaning, maintenance and repair.

Other Features

• Maxx Duty Driveshafts, the same as the new ones Traxxas are putting in their 4S capable Maxx truck with beefed up u-joints and shaft diameter
• Upgraded Slipper Clutch with larger alloy pressure plates and high temp aluminium pads for superior power distribution from side to side and front to back.

• Ultra Shocks have been on some of Traxxas premium 1:10 scale trucks and have been around a long time. Tried and true performance hydraulic dampening.

• Deep Wall Battery Compartment with a hinged, double sided, latchable battery strap protect your Lipo batteries even in the worst crashes.
• 3-Channel Receiver with Fail Safe Security built in, will stop Bigfoot from driving away at top speed in the event of battery failure in the radio. The receiver returns the throttle to neutral and holds the last steering position.
• Dual Steering Bellcrank Assembly with Servo saver provides zero bump steer geometry, smooth turning action and equal delivery of steering power to both front wheels whilst a heavy duty, cam style servo saver guarantees protection for the servo from impact damage.
• Extra Meaty One Piece Camber Links, really hard to damage, even in a crash, maintain the proper steering geometry and never require adjustment
• Heavy Duty Suspension Components are engineered for strength and durability, minimising wear and tear damage from dramatic driving and terrain hazards.
• Rubber Sealed Bearings throughout; diffs, bellcrank and hubs, for minimal loss of power through friction.
• 32 Pitch Gearing for extra toughness in the driveline. 32P is much less likely to strip in a crash and provides a solid gear mesh.
• Metal Differentials, extra tough to handle all that power without stripping. Crown gear, pinion, spider and sun gears, all steel.

Specs:

Length: 514mm
Width: 333mm
Ground Clearance: 62mm
Weight: 2.7kg without batteries
Height: 235mm
Wheelbase: 295mm
Front Shock Length: 88mm - Long
Rear Shock Length: 101mm - XX-long
Tires:    2.2″ Terra Groove with foam inserts
Wheel Diameter: Dual-profile 2in outer, 3in inner white monster truck
Speed Control: BL-2s electronic speed control
Motor (electric): BL-2s 3300 Kv sensorless brushless
Gear Pitch: 32 pitch
Overall Drive Ratio: 15.36:1
Differentials: Hardened steel bevel, sealed, limited slip
Chassis Structure / Material: Modular composite tub
Brake Type: Electronic
Drive System: Shaft driven 4WD
Steering: Dual bellcrank with integrated servo saver
Radio System: TQ 2.4 GHz 2-channel and 3 channel receiver with Fail Safe
Servo: Waterproof #2075 9kg
Skill Level: 1
Battery Compartment (L/W/H): 162mm x 47mm x 2 mm
Required Batteries: 4 AA alkaline batteries for the transmitter

Whats In The Box:

• Traxxas 1:10 scale Bigfoot 4x4 Monster Truck
• TQ 2.4ghz transmitter
• Booklet with spare parts list and exploded diagrams
• Traxxas glossy brochure
• Allan keys and a wheel nut spanner

What You Need:

• 7.4V 2S Lipo battery with Traxxas plug or 8.4V Nimh battery
• Suitable battery charger
• 4 AA alkaline batteries for the radio
