DUALSKY 480size Tuning Combo w/ 2316C 1250kv Brushless Motor & 45A Lite ESC - DSTC.3A.480
DUALSKY 480size Tuning Combo w/ 2316C 1250kv Brushless Motor & 45A Lite ESC - DSTC.3A.480
Regular price
$109.95
Regular price
Sale price
$109.95
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
DUALSKY 480size Tuning Combo w/ 2316C 1250kv Brushless Motor & 45A Lite ESC - DSTC.3A.480
This tuning combo from Dualsky includes an ECO 2316C 1250kv Motor and 45A Lite ESC. This package will suit 480-size RC planes with a flying weight of 600-1200g or 450 size helicopters. The combo develops approximately 260 watts on 3S. It is compatible with the V2 programming card.
Features
- Comes with ECO 2316C motor and XC-45-Lite ESC
- Ideal for 480-size RC planes or helicopters
- Compatible with the V2 programming card
Specs
- Motor RPM/V (KV) - 1250
- Motor Shaft Diameter (mm) - 3
- Motor Mounting Holes Pitch - 16/19
- Motor Weight (g) - 70
- Motor Resistance (Ri)(mOhm) - 52
- Motor Idle Current (Io) @10V (A) - 1.1
- Motor No.of Cells (LiPo) - 2-3
- Motor Max. Efficiency Current (A) - 20
- Motor Max. Burst Current (15s)(A) - 28
- Motor Approximate Max. Power (15s) (W) - 260
- Motor Input Connectors - 3.5
- Motor Recommended ESC - XC-45-Lite
- Motor Prop. Range - 10x5, 12x6
- Motor App. Class - 600-1200g
- ESC Dimensions (L x W x D) (mm) - 67x 25x 7
- ESC Weight, with wires (g) - 38
- ESC Number of Cells (NiXX) - 5-9 cells, 6-10.8V
- ESC Number of Cells (LiPo) - 2-3s, 7.4-11.1V
- ESC Resistance(Ri)(Ohm) - 0.0026
- ESC Max Cont. Current & Max Cont.Output - 45A, 500W
- ESC Max Burst Current & Max Burst Output - 60A, 666W
- ESC BEC / Dissipative Power - 5.2V/3A (Linear)
- ESC Programmable - Throttle + ProgCARD V2
- ESC Signal Wire - 300MM JR
